PEEK Reducer

PEEK Reducer

联系二维码

Scan the code to enquire about the product

Product Description

The PEEK Reducer is manufactured from polyether ether ketone (PEEK) and its composite materials. By replacing traditional metal components in key parts of the reducer, it addresses the challenges associated with reducers—particularly precision reducers—such as excessive weight, high noise levels, lubrication issues and corrosion. It features a lightweight structure, high transmission efficiency, low noise and excellent wear resistance. By replacing traditional metal reducers, it delivers precise power transmission for humanoid robots, drones and other equipment, serving as a key component for flexible motion and extended endurance in high-end equipment. It is 50% lighter than aluminium alloy and 50%–70% lighter than stainless steel, achieving an ideal balance between lightweight construction and high strength. It can be applied to rotary joint modules in humanoid robots. For harmonic and cycloidal reducers, weight reduction can reach 40–70 per cent. It is suitable for the elbows, wrists, knees and ankles of robots, reducing impact and wear on metal parts and improving transmission stability. With outstanding anti-creep properties, it maintains long-term meshing accuracy and stable precision.

Product Specifications

The core components of this PEEK reducer are precision-moulded from a modified polyether ether ketone composite material. It has a density of just 1.3–1.5 g/cm³, making it 50% lighter than aluminium alloy and 40%–70% lighter than stainless steel. It features a tensile strength of ≥ 100 MPa, a flexural strength of ≥ 165 MPa, and a notched impact strength of ≥ 7 kJ/m², maintaining stable mechanical properties across a wide temperature range of -40°C to 260°C to meet the complex operating conditions of robots. It exhibits a low coefficient of friction of 0.2–0.3 under dry conditions, with outstanding self-lubricating properties. The reducer delivers high transmission accuracy and excellent transmission efficiency, together with high repeat positioning accuracy and excellent creep resistance, ensuring high retention of long-term meshing accuracy. Suitable for mainstream reducer types, including harmonic and cycloidal reducers, it features low operating noise, corrosion resistance and ageing resistance, making it suitable for multi-environment applications. It perfectly meets the requirements of lightweight, high-precision and long-life transmission for humanoid robot joints.

Company Profile

Zhongyan Composites (Shenzhen) Technology Co., Ltd.

Zhongyan Composites (Shenzhen) Technology Co., Ltd. serves as the innovation centre and industrialisation base for high-performance polymer applications within the Zhongyan Group. It leverages the strengths of its parent company, which holds National High-Tech Enterprise status, acts as the lead drafter of the national standard for polyetheretherketone (PEEK), and possesses 35 domestic and international invention patents alongside numerous system certifications. The company specialises in the polymerisation, application development and precision moulding of PEEK materials, driving innovation to provide customers with solutions for upgrading critical components. Leveraging the lightweight, self-lubricating and high-strength properties of PEEK materials, the company provides specialised materials and customised moulding services for critical components such as robotic joint transmission parts, gears, bearings and limb skeletons. This enables weight reduction and noise reduction in components, significantly enhancing robotic endurance and movement flexibility. Possessing core technologies and advanced equipment across the entire industrial chain, the company offers a full-process service tailored to client requirements, encompassing material selection, modification formulation research, process evaluation and optimisation, prototype validation and mass production. This enables the creation of efficient and viable one-stop product solutions, supporting the robotics industry’s transition towards lighter and more precise designs.
