ELECTRONIC SKIN TACTILE PERCEPTION SYSTEM

electronic skin treatment passion system

联系二维码

Scan the code to enquire about the product

Product Description

The company utilises world-leading flexible tactile solutions and fabrication processes to develop integrated flexible electronic skin tactile chips (referred to as “electronic skin”) that are multimodal, highly sensitive, stretchable (elastic) and feature high array density for the simultaneous acquisition and feedback of multiple physical signals. Electronic skin is an advanced sensing system that densely integrates various types of tactile sensing units onto a flexible polymer substrate. It is capable of detecting and perceiving a wide range of physical signals, including pressure, temperature, proximity, shear stress, sliding, and surface texture. Furthermore, it incorporates signal pre-processing, transmission and feedback functionalities. Several of the technologies employed represent world-first innovations.

Product Specifications

Electronic skin tactile perception system Detection Signals: Pressure, temperature, proximity, shear stress, sliding Number of Independent Sensors: Default: 4096 (adjustable) Surface Coverage: Supports full surface coverage and large-area wrapping Stretchability: 20%–50% (adjustable) Force Measurement Range: 0–100 N/cm² (adjustable) Force Resolution: 0.02 N/cm² Temperature Measurement Range: -20°C to 90°C Temperature Resolution: 0.5°C Maximum Detection Distance: 150 mm Distance Resolution: 1 mm Dimensions: 5 mm to 1000 mm (customisable) Thickness: 0.1–1 mm Spatial Resolution: 0.5 mm (customisable) Service Life: greater than 1 million cycles Sampling Frequency: 50 Hz (1–100 Hz adjustable) Accuracy: 11 TP3 TFS Hardness: 10–50 A (customisable) Other features: Impact-resistant, Waterproof, Anti-interference, Power consumption

Company Profile

Tujian Technology (Beijing) Co., Ltd.

TuJian Technology Co., Ltd. was established in early 2020. Headquartered in Beijing, the company has wholly-owned subsidiaries in Shenzhen and Guangzhou, as well as a cutting-edge technology research centre in Silicon Valley, USA. The company specialises in the research and development of stretchable, multi-modal flexible electronic skin haptic perception systems, as well as the construction of embodied intelligence haptic perception big data models; several of the flexible electronic skin technologies it has developed are world-firsts. Leveraging its robust in-house R&D capabilities, the company has been selected as one of the first organisations to undertake the National Key R&D Programme’s Disruptive Technology Innovation Project under the Ministry of Science and Technology. The company provides clients with comprehensive tactile sensing solutions and has established strategic partnerships with numerous listed companies and industry leaders.
