Integrated Servo Wheel Hub (UM series)

联系二维码

Scan to Inquire About the Product

Product Description

The integrated servo hub combines the servo hub motor, driver and encoder, offering a compact design, easy installation and simple operation. Although slightly thicker than a separate servo hub motor, it significantly reduces the space required for installation by eliminating the need for external drivers and cables, thereby optimising chassis design. Its enhanced thermal design also ensures an overload capacity equivalent to that of a split-type servo hub motor.

Product Specifications

It operates exceptionally quietly, being almost inaudible at 20 RPM, and incorporates a high-precision encoder with an accuracy of up to 21 bits. The system boasts a powerful load capacity, supporting weights of up to 350 kg in a two-wheel differential drive configuration, and maintains stable operation even at speeds as low as 1 RPM. To ensure safety, it features 200% overload protection and exceptionally short braking distances.

Company Profile

Beijing Hollysys Motor Technology Co., Ltd.

Founded in 2000, the company is a state-level high-tech enterprise and a ‘Specialised, Refined, Distinctive and Innovative’ (SEDi) ‘Little Giant’ enterprise. Its core business encompasses servo motors, stepper motors, drivers, motion control systems and bespoke solutions. The company’s products are widely used in industrial robotics, smart logistics, medical devices and new energy equipment, providing core power support for smart manufacturing. As a leading enterprise in the industry, the company has obtained certification for the ISO 9001 Quality Management System and the ISO 14001 Environmental Management System. It has filed over 100 national patent applications, of which 30% are invention patents, holds more than 20 software copyright registrations, and has taken the lead in formulating numerous industry technical standards. Its independently developed precision winding control system has filled a technological gap in the domestic market, with key technical indicators reaching internationally advanced levels; its multi-degree-of-freedom networked control system pioneered the application of servo motors in the cultural industry in China; and products such as low-voltage servo motor drive systems and servo hubs specifically designed for intelligent logistics equipment are at the forefront of domestic technology. The company’s objective is to fully leverage its technical strengths to drive market-led equipment innovation. Through sustained and stable development, it aims to provide clients with technologically advanced professional services, whilst striving to become a long-standing specialist in the field of motion control.
