Sizector®3D Camera-SXN series, which carries multi projectors and Hardware Computation lmaging technology. lt eliminates shadows and blind spots caused by single-direction projection imaging and solves issues like outliners, holes that commonly occur on highly reflective surfaces. Widely applicated in Semiconductor, lithium Battery, PCBA, Connector, New Energy Vehicles and etc, industries.
Product Specifications
1. Eliminate shadow and high reflection interference, achieving higher integrity of 3D point cloud: Utilize multi-projection technology to capture multiple sets of 3D point clouds from different projection directions for hardware fusion, resulting in higher integrity. 2. High accuracy and high speed: After multi-3D fusion at the camera hardware end, high-precision 3D point cloud is output. Compared to PC-based systems, the data transmission volume is significantly reduced without increasing computing time. 3. Use telecentric lens, pixel-level alignment of 2D and 3D data: Combined with external light sources for synchronization, it realizes 2D + 3D integrated measurement and detection. The external RGB light source can obtain true-color 3D point cloud without Bayer matrix and 3CCD imaging effect.
