Planetary Joint Module

Planetary Joint Module

联系二维码

Scan the code to enquire about the product

Product Description

It integrates high-power-density motors, high-precision planetary gearboxes and advanced servo drive technologies to achieve integrated control. It delivers high torque output and high dynamic response, ensuring precise and efficient motion of robot joints. A power solution specially designed for high-end equipment such as quadruped robots and humanoid robots.

Product Specifications

Model｜DB6065-P30-C Reduction Ratio｜30 Rated Voltage｜48V Rated Current｜6.5A Rated Power｜312W Rated Speed｜115 rpm Rated Torque｜17 Nm Peak Speed｜167 rpm Peak Current｜14. 9A Peak Torque｜50Nm Unit Weight｜500g Reducer Backlash｜10–15 arcmin Product Dimensions (D×L)｜60×65mm Dual Encoder｜Yes Communication Protocol｜CAN FD Communication Baud Rate｜5Mbps Bore Size｜4mm

Company Profile

Suzhou Derby New Power Co., Ltd.

Suzhou Derby New Power Co., Ltd. was established in 2021. Focusing on the field of key robotics components, the company specialises in products such as joint modules, linear actuators and micro servos. Committed to end-to-end in-house R&D and collaboration with supply chain partners, the company provides customers with integrated product solutions that are of high quality, high performance and high reliability.
